Battery tester
The 300A 12/24V Battery Load Tester with AMP & VOL Meter is designed for practical load testing of 12V and 24V batteries. With a load test capacity of 300 amps, this tester provides a direct method of checking battery performance under load and is suitable for a wide range of automotive and vehicle service applications.
The tester is designed for batteries with a capacity of 21-200Ah. A built-in switch allows the user to select the appropriate battery capacity during testing, helping adapt the test process to batteries with different capacity ratings. This makes the unit suitable for routine inspection and maintenance work where different battery sizes may be handled.
The display meter has a range of 8-16V, providing a clear voltage reference during battery testing. The unit also features an AMP & VOL meter configuration, giving the tester a distinctive panel design and allowing users to monitor the relevant electrical readings during operation.
With support for both 12V and 24V battery testing, this model offers broader vehicle application coverage than a standard 12V load tester. It can be used in automotive workshops, battery service centers, vehicle maintenance businesses, and other professional battery testing environments.
The tester focuses on direct load testing rather than advanced electronic battery analysis. Its 300A load capacity, 12/24V application, 21-200Ah battery range, and AMP & VOL meter configuration make it a practical option for users who need a straightforward battery testing tool.
Specifications
- Application: 12/24V Battery Test
- Load Test Capacity: 300 amps
- Battery Capacity: 21-200Ah
- Display Meter: 8-16V
- Meter Configuration: AMP & VOL Meter
- Battery Capacity Selection: Switch for choosing battery capacity
- Size: 35 × 19 × 14cm
